Availability: Excepted lead time is 0-5 days.
Compatibility:
- Any trailer with a ball receiver weighing less than 4,000 or 6,000 lbs on level ground (select desired towing capacity) and a tongue weight of less than 600 lbs
Transit Time: 1-5 business days domestic and 3-8 business days international
Description: The AirTug® Model TT-LD Light Duty Trailer Tug – Electric – Manual or Automatic Ball Lift is extremely easy to use because of its’ “Thumb Throttle Control” system utilizing an electric transaxle with differential as the heart of this trailer tug. There are no gears to shift and no jerky clutching systems to quickly wear out. It utilizes an electric motor so no need to worry about fuel problems. The hitch ball or pintle hitch raises and lowers with the push of a button on the Automatic Model making it quick and easy to attach a trailer. We ensure your safety with our “Return to Brake” feature that prevents any unintentional movement of the trailer when the thumb throttle is released. Finally, its’ pinpoint handling makes this unit a great choice. All of these features simply make this trailer mover the best in the industry!
Please note: Any grade significantly increases the effective weight of the trailer. (For example: 3 degrees or roughly 5% of slope increases the effective or perceived trailer weight by roughly 50%)
Product Details
- Tow Weight: Up to 4,000 or 6,000 lbs GTW
- Tongue Weight: Up to 600 lbs
- Ball Sizes: 1-7/8″, 2″ and 2-5/16″
- Ball height from ground: starts at approximately 21″ and can be raised approximately 6″ to 27″ for manual or automatic
- Motor: Heavy Duty Electric Permanent Magnet Motor
- Electric Transaxle with Differential for Precision Handling and Easy Turning
- Type of Control: Unique Thumb Throttle
- Turning Radius: 360 ◦
- Surge Brake Bypass option
- Parking Brake option
- Two (2) 12V U-1 batteries and a charger included
- Parts Warranty: 1 Year
- 30 Day Money Back Guarantee!!!
Construction Details
- Powder Coated 11 Gauge Heavy Steel Frame
- 13″ Drive Wheels capable of handling tongue weights up to 600 lbs
- Product Dimensions: 54″ x 31.5″ x 46″ Weight 310-320 lbs
Shipping Details
- Fully Assembled
- Skidded for truck shipment (skid: 57” x 34” x 51” Weight 370-380 lbs)
